P-82126-GV / P-82126TRC-GV
Working width |
82" / 2083 mm |
HP recommended |
50 à 70 ch pdf |
| Cutting height | 30" / 762 mm |
| Drum diameter | 26" / 660 mm |
| Weight | Reg.: 1270 lbs / 577 kg TRC: 1380 lbs / 627 kg |
Options
CHOICE OF CHUTE
PC3C-GR1.5
| 3-Deflector semi-industrial chute with greasable hinges and removable access panel. | PC3C-GR1.5 |
| Quick attach industrial chute with greasable hinges and access panel (removable). | PCG3C-GR1.5 |
| 48" extension for industrial chute. | PRP-GR1.5 |
CHOICE OF ADJUSTMENT FOR CHUTE DEFLECTOR
25TR04
| Hydraulic cylinder | 25TR04 |
HYDRAULIC MOTOR FOR CHUTE ROTATION
| Hydraulic motor (included) | MLH-250-R |
HOSE KITS
PKB-GR1
PKB-GR1TRC
| Hose kit for basic functions. Includes hydraulic hoses connecting the tractor oil outlets to the deflector adjustment cylinder and the chute rotation motor. * Installation not included. | PKB-GR1 |
| Kit for TRC models, also includes hoses for drum rotation motor. * Installation not included. | PKB-GR1TRC |
SCRAPER BLADE
SIT1-182
TV-182
SST-182
| Semi-industrial scraper blade, Hardox 450, reversible, 1/2" x 3 1/2", not sharpened | SIT1-182 |
| Tivar scraper blade, 1" thick, not reversible, including mounting kit | TV-182 |
| Stainless steel scraper blade, reversible, 1/2" x 3 1/2", not sharpened | SST-182 |
SKID SHOES
PHD-4872
PST-4872
| Industrial skid shoes with Hardox 450 soles | PHD-4872 |
| Skid shoes with stainless steel soles | PST-4872 |
SPEED REDUCER
PR-7502-1
PR-7202-2
PRC-6502-1
| Inverter 540/540 RPM (1:1) - 75 HP at 540 RPM - 2 gears - shafts 4.855" c/c | PR-7502-1 |
| Speed reducer inverter 1000/555 RPM (1.8:1) - 85 HP at 1000 RPM - 2 gears - shafts 4.855" c/c | PR-7202-2 |
| Non-inverting PTO drop box 540/540 RPM (1:1) - 55 HP at 540 RPM - chain - shafts 6.5" c/c | PRC-6502-1 |
CHOICE OF POWER TAKE-OFF (PTO)
| T50 PTO 1 3/8"-6 & 1 3/8"-6 (540 RPM) | 8114 |
| T60 PTO 1 3/8"-6 & 1 3/8"-6 (540 RPM) | 8202 |
| T60 PTO 1 3/8"-21 & 1 3/8"-6 (1000 RPM) | 8202-1 |
HYDRAULIC MOTOR FOR ROTARY DRUM (TRC MODELS ONLY)
| Hydraulic motor (included on TRC model) | MLH-250 |
RUBBER DEFLECTOR FLAP
| Rubber deflector flap located from the top of the frame to the auger. Reduces projections. | TL-8092 |
CHOICE OF COLORS
| Red PRONOVOST | |
| Blue | PG1-02 |
| Orange | PG1-04 |
| Yellow INDUSTRIAL | PG1-06 |
| Green | PG1-07 |
| Black | PG1-10 |
Additional Information
HYDRAULIC DRIVEN
It is possible to use this snowblower with hydraulic drive. The hydraulic oil flow at a specific pressure will guide you in to the choice of the snowblower.
Contact your Pronovost dealer to obtain a quote for your specific requirements.
HYDRAULIC WHEELS
Hydraulic wheels permit using the snowblower at a constant height from the ground without scraping it.
- Practical to avoid blowing gravel.
- Permit snowblowing on a grassy surface while avoiding direct contact of the blade with the ground.
Contact your Pronovost dealer to obtain a quote for your specific requirements.
*Available only on a new snowblower made in production.
Complete specifications
| HP recommended (min. - max.) | 50 to 70 HP PTO |
| Working width | 82" / 2083 mm |
| Cutting height | 30" / 762 mm |
| Hitch category | 1 |
| Cutting height of lateral blades | 39 1/2" / 1003 mm |
| Impeller diameter | 26" / 660 mm |
| Depth of drum | 12" / 305 mm |
| Impeller housing contour : Hardox 450 | Included |
| Number of impeller blades | 4 |
| Impeller shaft diameter | 1 9/16" / 40 mm |
| Height of impeller center | 16 1/2" / 419 mm |
| Rotor RPM | 540 RPM |
| Required RPM for the tractor PTO | 540 RPM - Opt. 1000 RPM |
| Number of augers | 1 |
| Main auger diameter | 25" / 635 mm |
| Bearing / ductile iron housing | 1 1/4" / 32 mm |
| Drive chain - Main auger | 60 |
| Number of shear bolts | 1 for impeller and 1 for auger |
| Drum rotation for hydraulic motor (TRC only) | MLH-250 |
| Drive shaft included (optional) | T50 (T60) |
| Lateral blades - High quality steel | Opt. |
| Scraper blade - High quality steel | 3/8" x 3 1/2" reversible |
| Scraper blade - Semi-industrial made of Hardox 450 | SIT1-182 |
| Scraper blade - Tivar | TV-182 |
| Scraper blade - Stainless steel | SST-182 |
| Adjustable skid shoes - Quick adjustment high quality steel | Included |
| Adjustable skid shoes - Quick adjustment Hardox 450 | PHD-4872 |
| Adjustable skid shoes - Quick adjustment stainless steel | PST-4872 |
| Chute - Regular | PC3C-GR1.5 |
| Chute rotation system - Hydraulic motor kit (motor not included) | MLH-250-R |
| Chute rotation maximum angle - Hydraulic motor rotation | 270° to 345° adjustable |
| Antifriction for chute | Ring |
| Deflector - Hydraulic cylinder | 25TR04 |
| Color | Pronovost Red |
| Storage support | Included |
| Weight | Reg.: 1270 lbs / 577 kg TRC: 1380 lbs / 627 kg |
| Weight including chute | 1270 lbs / 577 kg |
| Weight including chute (TRC model) | 1380 lbs / 627 kg |
